Mission
The MQ-9 Reaper is an armed, multi-mission, medium-altitude, long-endurance remotely piloted aircraft that is employed primarily against dynamic execution targets and secondarily as an intelligence, surveillance, and reconnaissance asset. Given its significant loiter time, wide-range sensors, multi-mode communications suite, and precision weapons -- it provides a unique capability to perform strike, coordination, and reconnaissance against high-value, fleeting, and time-sensitive targets.
Reapers can also perform the following missions and tasks: intelligence, surveillance, reconnaissance, close air support, combat search and rescue, precision strike, convoy/raid overwatch, target development, and terminal air guidance. The MQ-9's capabilities make it uniquely qualified to conduct operations in support of combatant commander objectives.
Features
The MQ-9 baseline system incorporates a targeting designator, which precisely designates targets for employment of munitions, low-collateral damage, anti-armor and anti-personnel engagement capabilities.
In its secondary role as an ISR asset, the MQ-9 is part of a system that support strike aircraft and ground commanders by acquiring and tracking dynamic targets or other useful reconnaissance. It is also capable of supporting a wide range of operations such as coastal and border surveillance, weapons tracking, embargo enforcement, humanitarian/disaster assistance, support of peacekeeping and counter-narcotic operations.
The primary concept of operations, remote split operations, employs a launch-and-recovery ground control station for take-off and landing operations at the forward operating location, while the crew based in continental United States executes command and control of the remainder of the mission via beyond-line-of-sight links. Remote split operations result in a smaller number of personnel deployed to a forward location, consolidate control of the different flights in one location, and as such, simplify command and control functions as well as the logistical supply challenges for the weapons system.
Background
The U.S. Air Force proposed the MQ-9 Reaper system in response to the Department of Defense directive to support initiatives of overseas contingency operations. It is larger and more powerful than the MQ-1 Predator, and is designed to execute time-sensitive targets with persistence and precision, and destroy or disable those targets. The "M" is the DOD designation for multi-role, and "Q" means remotely piloted aircraft system. The "9" indicates it is the ninth in the series of remotely piloted aircraft system
General characteristics
Primary function: find, fix, and finish targets
Contractor: General Atomics Aeronautical Systems, Inc.
Power plant: Honeywell TPE331-10GD turboprop engine
Thrust: 900 shaft horsepower maximum
Wingspan: 66 feet (20.1 meters)
Length: 36 feet (11 meters)
Height: 12.5 feet (3.8 meters)
Weight: 4,900 pounds (2,223 kilograms) empty
Maximum takeoff weight: 10,500 pounds (4,760 kilograms)
Fuel capacity: 4,000 pounds (602 gallons)
Payload: 3,750 pounds (1,701 kilograms)
Speed: cruise speed around 230 mph (200 knots)
Range: 1,150 miles (1,000 nautical miles)
Ceiling: Up to 50,000 feet (15,240 meters)
Armament: combination of AGM-114 Hellfire missiles, GBU-12 Paveway II and GBU-38 Joint Direct Attack Munitions
Crew (remote): 1 Pilot, 1 Sensor Operator
Unit cost: $64.2 million (includes four aircraft, sensors, GCSs, and Comm.) (fiscal 2006 dollars)
Initial operating capability: October 2007
Inventory: total force, 93
(Current as of September 2015)
